NEMA Standard Motors
NEMA Design B
Frame Size : 143T～449T
Output Power : 1～300 HP
Rated Voltage : 208-230 V/ 440 V , Other Voltage Can Be Customized
Rated Frequency : 50 Hz , 60 Hz
Guangzhou Haoqing Mechanical And Electrical Equipment Co., Ltd. is one of the leading manufacturers and suppliers of nema standard motors in China. Welcome to buy high-grade nema standard motors made in China here from our factory. All customized products are with high quality and low price.
|
NEMA Design B |
|
| Frame Size | 143T～449T |
| Output Power | 1～300 HP |
| Rated Voltage |
208-230 V/ 440 V , Other Voltage Can Be Customized |
| Rated Frequency | 50 Hz , 60 Hz |
| Insulation Class | F ,H |
| Duty | S1 |
| Service Factor | 1.1 ～ 1.25 |
| Protection Class | IP55 ,IP56 |
| Cooling Method |
IC411, Other Cooling Method Can Be Customized |
| Mounting | T, TS ,TC |
| Ambient Temperature |
-20 ℃～40 ℃ , Other Ambient Temperature Can Be Customized |
| Altitude | ≤1000 m |
| Stator Coil |
100% Pure Copper By Vacuum Pressure Impregnation (VPI) |
| Thermistor (PTC,PT100) ,Heater is available on request | |
| Rotor Coil | Squirrel-Cage |
| Long Shaft Can Be Customized | |
Product Overview:
NEMA design B motors are totally enclosed self-fan-cooled three-phase asynchronous motor (Squirrel -Cage Induction Motor). The premium efficiency motors are developed by ourselves independently according to NEMA Premium Efficiency of NEMA EPACT. The output rated power and mounting dimensions of the motors are perfectly in accordance with NEMA. NEMA premium motors is reasonable structure, small vibration and low noise.
NEMA Premium series 3- phase asynchronous motors can be widely used in blowers, ventilators, pumps, machine tools, compressor, reducers, packing machines, transportation machinery, mining equipment, construction equipment and other machines which can operate with full load for a long time, the electrical motors can save the considerable electric energy, it is advantageous to protect the environment.
NEMA design B motors have the characteristics of simple installation, low noise, high starting torque, low starting current, long bearing life, etc., and can meet the VFD operation
For more technical data and dimensions of motors, please contact us
