Cooling Method IC511 High Voltage Slip-Ring AC Motors
High Voltage Slip-Ring AC Motors Cooling Type :IC511
Frame Size : 450～1120
Output Power : 185～15000 kW
Rated Voltage : 3000 V ～ 13800V,Low Voltage Can Be Customized
Rated Frequency : 50 Hz , 60 Hz
Guangzhou Haoqing Mechanical And Electrical Equipment Co., Ltd. is one of the leading manufacturers and suppliers of cooling method ic511 high voltage slip-ring ac motors in China. Welcome to buy high-grade cooling method ic511 high voltage slip-ring ac motors made in China here from our factory. All customized products are with high quality and low price.
|
High Voltage Slip-Ring AC Motors Cooling Type :IC511 |
|
| Frame Size | 450～1120 |
| Output Power | 185～15000 kW |
| Rated Voltage | 3000 V ～ 13800V,Low Voltage Can Be Customized |
| Rated Frequency | 50 Hz , 60 Hz |
| Insulation Class | F or H |
| Duty | S1 |
| Protection Class | Totally Enclosed Type,IP54 , IP55 , IP56 |
| Cooling Method | IC511 |
| Mounting |
B3 |
| Ambient Temperature | -20 ℃～40 ℃ Other Temperature Can Be Customized |
| Altitude | ≤1000 m Other Altitude Can Be Customized |
| Stator Coil |
100% Pure Copper By Vacuum Pressure Impregnation (VPI) |
| Thermistor (PTC,PT100) ,Heater is available on request | |
| Rotor Type | Slip-Ring Rotor, Wound-Rotor |
| Standard | IEC60034 |
|
Motor Dimensions Can Be Customized |
|
Product Overview:
High Voltage Slip-Ring AC Motors Cooling Type :IC511 (Wound- Rotor Motors) complies with IEC 60034 standards. Cooling type : air-air cooling .
The housing structure of this motor is a steel plate welded structure, with cooling ducts inside the motor. The advantage of this structure is that the motor can be produced in standard sizes or customized according to user requirements. This type of motor is compact and is usually used in places where space is relatively limited.
For detailed parameters and drawings of the motor, please contact us.
